Full Height Turnstile DS403
- Model DS403 is a secure entrance turnkey solution for both indoor and outdoor environment that requires high security, like transportation terminals, construction field, sports facilities.
- The movement with absorber structure, making the product operate very quietly.
- Whole material is made of full brushed stainless steel, long-lasting durable, strong and robust.
- Visible LED indicators are placed on top and sides. Each passage has two LED to show entry or non-entry.
- The arm is 120ยฐ with 3 sections or 90ยฐwith 4 sections for optional.
- Itโs with enough space and can firmly install any kind of access controller and device, light RFID reader, biometric device, QR/Barcode reader ect.
Features of Daosafe Full Height Turnstile
- Long-life performance, high operation dependability and fast response
- The mechanism is equipped with an automatic regulated hydraulic buffer device. No noise and impact when running
- Single directional or Bi-directional is selectable
- Automatic reset function: turnstile arm will lock automatically within 5s (can be setting) if passenger delay to entry
- Anti-tailing function: only one person passes at one time
- When power is off, arms will open automatically, which is complying with fire safety requirements
- LED indicator (red ร means no entry; green โ means entry)
- Structure of trunking to contain cable tidy inside the case
- Structure of ring cover on top and bottom to beautify it
- Override key function: when power failure, support to control open and close by manual
- Easy to install and maintain
- 3-year warranty support
Product Details and Dimensions
All the details and dimensions can be customized according to your project site
Full 304 stainess steel
1 of 4LED indicator
2 of 4RFID card reader
3 of 4Bearing base cover
4 of 4
Product Parameters
| Model No. | DS403 |
|---|---|
| Brand | Daosafe |
| Framework Material | 304 Full Stainless Steel |
| Dimension | 3600 * 1460 * 2240mm |
| Weight | 450kg/pcs |
| Passage Width | 3 Lanes, 625mm/lane |
| Arm Support | 120ยฐ rotors with 3 sections or 90ยฐ rotors with 4 sections |
| Passing Direction | Single directional / Bi-directional |
| MCBF | 10 million |
| Power Supply | AC220V/110V, 50/60Hz |
| Operation Voltage | 24V DC |
| Power Consumption | 40W |
| Operation Temperature | -15 ยฐC - 60 ยฐC |
| Operation Humidity | 0 ~ 95% (No freeze) |
| Working Environment | Indoor / Outdoor |
| Flow Rate | 30 people per minute |
| LED Indicator | Yes |
| Emergency | Automatic arm open when power off |
| Communication | Dry contact, Relay signal, RS485 |
We Provide Mutiple Solutions
Can integrate a variety of access control equipments
Easy Installing, NO Need Any Special Electrician Skills
Fix on ground, connect to power supply, it will work
Clients Gallery
Click on images to enlarge
The Football Field in UK 2
The Football Field in UK 1
DS402FS Full Height Turnstile in Olympic Stadium in Oran, Algeria-1
DS402FS Full Height Turnstile in Olympic Stadium in Oran, Algeria-2
The Distribution Center in Ecuador 2
The Factory in Angola
The Distribution Center in Ecuador 1
