Pedestrian Security Gate DSSP6003C
- DSSP6003C half-height pedestrian security gate is designed for individual operation or to integrate with a half-height turnstile for access control.
- The body is made of brushed stainless steel +glass, which is anti-rust, durable, and good looking.
- It features a standard relay signal for compatibility with various third-party access control systems. This setup is a common and ideal solution for managing access for package deliveries, carts, handicapped individuals, and similar needs.
- The system can well match with various models of Daosafe turnstiles and speed gates to use.
- The direction of door opening: two-way.
- Green and red LED indicator display passing status.
Features of Daosafe Pedestrian Security Gate
- Whole product is in full industrialized design, produced for high/low temperature, and dusty hazardous environment
- It has various design for optional
- The pedestrian length and height of pedestrian gate is can be customized
- The system is mainly design to enclose open space or for handicapped passing
- It is suitable for both indoor and outdoor applications
- Easy to install and maintain
- 3-year warranty support
Product Details and Dimensions
All the details and dimensions can be customized according to your project site
Full 304 stainless steel
1 of 3Handicapped passing
2 of 3Access controller
3 of 3
Product Parameters
| Model No. | DSSP6003C |
|---|---|
| Brand | Daosafe |
| Type | Motor with clutch |
| Framework Material | 304 Full Stainless Steel + Plexiglas Arm |
| Direction of Door Open | Two ways |
| Dimension | 1390 * 120* 1245(mm) |
| Passage Width | 900mm |
| Weight | 35kg/pcs |
| MCBF | 10 million |
| Power Supply | AC220V/110V, 50/60Hz |
| Operation Voltage | 24V DC |
| Power Consumption | 20W |
| Operation Temperature | -15 °C - 60 °C |
| Operation Humidity | 0 ~ 95% (No freeze) |
| Working Environment | Indoor / Outdoor |
| Emergency | Automatically open when power off or fire alarm |
| LED Indicator | green → entry, red × no entry |
Product Comparison
Easy Installing, NO Need Any Special Electrician Skills
Fix on ground, connect to power supply, it will work
