Tripod Turnstile DS1000S
- DS1000S is a tripod turnstile with twin rotate arms, one cabinet with two 550mm passageways to improve traffic efficiency.
- The biggest feature of this product is its wide body of 520mm, which can integrate any size of third-party door equipment. For example, ESD, LCD, and other devices. And because of its width, it is heavy and sturdy, making the product very secure.
- The model is made of brushed stainless steel and also with black stoving varnish, which makes it looks more unique and artistic than other models.
- For the body, it’s slim and arc shape, which make it unique and can better protect people from crush injury.
- Front body is with bright, long and slim LED indication bar to make it more dazzling and attractive.
- With all-weather and environment capability, it can be applied both indoor and outdoor sites such as park, gym and office.
Features of Daosafe Tripod Turnstile
- Long-life performance, high operation dependability and fast response
- The whole system runs smoothly, low noise, no mechanical impact
- Single directional or Bi-directional is selectable
- Automatic reset function: turnstile arm will lock automatically within 5s (can be setting) if passenger delay to entry
- Anti-tailing function: only one person passes at one time
- When power is off, arms will open automatically, which is complying with fire safety requirements
- LED indicator (red × means no entry; green → means entry)
- Easy to install and maintain
- 3-year warranty support
Product Details and Dimensions
All the details and dimensions can be customized according to your project site
Full 304 stainless steel
1 of 4LED indicator
2 of 4LED indicator
3 of 4RFID card reader
4 of 4
Product Parameters
| Model No. | DS1000S |
|---|---|
| Brand | Daosafe |
| Framework Material | 304 Full Stainless Steel |
| Dimension | 1400 * 520 * 1000mm |
| Weight | 110kg/pcs |
| Passage Width | 550mm (Arm length: 500mm) |
| Passing Direction | Single directional / Bi-directional |
| MCBF | 10 million |
| Power Supply | AC220V/110V, 50/60Hz |
| Operation Voltage | 24V DC |
| Power Consumption | 40W |
| Operation Temperature | -15 °C - 60 °C |
| Operation Humidity | 0 ~ 95% (No freeze) |
| Working Environment | Indoor / Outdoor |
| Flow Rate | 35 people per minute |
| LED Indicator | Yes |
| Emergency | Automatic arm open when power off |
| Communication | Dry contact, Relay signal, RS485 |
We Provide Multiple Solutions
Can integrate a variety of access control equipments
Easy Installing, NO Need Any Special Electrician Skills
Fix on ground, connect to power supply, it will work
Clients Gallery
Click on images to enlarge
The Sportswear Store in Ireland 1
The Sportswear Store in Ireland 2
The Sportswear Store in Ireland 3
The Boxing Club in Estonia 1
DS1000 Tripod Turnstile Building Project in Dominica-1
DS1000 Tripod Turnstile in Egypt -4
DS1000 Tripod Turnstile Building Project in Dominica-2
DS1000 in Gym of Albania-2
DS1000 Tripod Turnstile Building Project in Dominica-3
DS1000 Tripod Turnstile in Egypt -1
DS1000 in Gym of Albania-1
DS1000S stairway project in Slovakia
The Stadium in Egypt 1
The Stadium in Egypt 2
The Boxing Club in Estonia
DS1000 Tripod Turnstile in Sri Lanka School-3
DS1000 Tripod Turnstile in Egypt -3
DS2000 Swing Turnstile in Egypt -1
Daosafe DS1000 Tripod Turnstile in Egypt -5
DS1000 Tripod Turnstile in Sri Lanka School-3
DS1000 Tripod Turnstile in Egypt -2
DS1000 Tripod Turnstile in Sri Lanka School-1
DS1000 Tripod Turnstile in Egypt -5
The Office Building in Turkmenistan
